Grace Design m108 8-channel remote preamplifier

THE FINEST SOUNDING, MOST CAPABLE MIC PREAMP WE HAVE EVER CREATED
From 25 years experience of creating acclaimed professional audio products, comes the latest evolution of our mic preamplifier design: the m108. With eight channels of our transparent, musical mic preamplification, state of the art A/D conversion, multiple digital output formats, and flexible local or remote controlled operation, the m108 is a vital addition to any modern audio production environment.

Our transformerless, transimpedance mic preamp design is unmatched in its ability to effortlessly resolve complex sonic waveforms, resulting in recordings of amazing clarity and depth. Integrated A/D conversion delivers digital signals to the workstation that are pure and beautiful. Latest generation s-Lock PLL ensures pristine, jitter free sample clock when clocking from external word clock or Dante clock. And an asynchronous mode USB interface provides the best possible jitter performance when connected to a computer.

SIMPLE OPERATION
A push-button rotary encoder is used for navigating and operation, with a user interface that is simple and intuitive. Dedicated push-buttons are assigned to core functions: 48V phantom power, phase reverse, channel grouping and meter peak clear. A crisp OLED screen displays complete system information, including channel gain settings, metering, peak status, and the system setup menu.

POWERFUL CONFIGURATION
Based on the acclaimed success of our m802 remote controlled mic preamplifier, the m108 distills the best of these achievements into a sleek, elegant 1U chassis design. Our transformerless, transimpedance mic preamp design is unmatched in its ability to effortlessly resolve complex sonic waveforms, resulting in recordings of amazing clarity and depth. Integrated A/D conversion delivers digital signals to the workstation that are pure and beautiful. Latest generation s-Lock PLL ensures pristine, jitter free sample clock when clocking from external word clock or Dante clock. And an asynchronous mode USB interface provides the best possible jitter performance when connected to a computer.

8 channels of balanced analog preamp outputs
8 channels of transparent, musical mic preamplier
Wide gain range: -8 to 74dB
Ribbon mic mode
8 channels of 192kHz ADC outputs via AES, ADAT (4chSMUX) and USB Class 2
External Word clock in and out
Reference DAC and headphone amplier for low-latency monitoring of channel pairs or USB playback from a computer
Channel 1 & 2 HI-Z inputs on front panel
High contrast, wide viewing angle OLED display forall system parameters and setup menu
Combination RS 485/422 serial / MIDI ports for control from existing m802 RCU or Protools™
Control App (Win and Mac, coming soon) can control upto 96 channels over Ethernet
Simple web browser control built in, works with all modern browsers including iOS and Android
RJ45 Ethernet port for network control
Expansion slot for optional Audinate / DANTE™ networkaudio card
Cooling fan for reliable operation in the harshestenvironments
Built in 100-240VAC universal AC power supply
