SPL GainStation 1 + ADC192

The GainStation 1 is a discrete high-end preamplifier that combines Class-A clean gain with high-sounding tube gain and operates with an operating voltage of 60 V.

Class-A meets Tube
The GainStation 1 is a hybrid preamplifier consisting of a discrete Class A transistor stage and tube stage. The hybrid design of the preamplifier combines the advantages of semiconductors (high dynamics with low distortion, low noise) with the musical qualities of tube sound (pleasant high/overtone spectrum, beautiful three-dimensionality).

The Class A transistor preamplifier is based on our DMPA operational amplifiers, which operate with an operating voltage of +/- 30 V.

The preamplifier has a Butterworth Hi Pass filter, polarity inversion, impedance selection, 48 V phantom power and a limiter.

AD Converter Module 1090:
The 24 bit converter module provides an SPDIF output which is available as coaxial and optical output.

The internal sampling rate can be set with switches to 44.1, 48, 88.2 and 96 kHz. Other sampling rates (32, 176.4, 192 kHz) can only be set with an external synchronization signal.

Features:
- Separately controllable transistor and tube preamplifiers
- The (switchable) tube stage delivers subtle to brutal tube saturation
- Only high-quality MKP film capacitors are used in the tube stage
- Peak/FET Limiter
- Polarity-reversal stage
- 48-Volt phantom power
- LED level indicator
- Switchable impedance adjustment for the microphone input (200 Ω, 1,2 - kΩ & 10 kΩ)
- Discrete operational amplifiers in Class A technology instead of industrial ICs
- Amplifier slew rate of <100 V/µs
- Gas-encapsulated relays with gold-plated contacts
- Resistors with 0.1 % tolerance in the entire audio path
- Power supply with double shielding, each voltage with its own winding and regulation
